30 kVA Three Phase Transformer 480V to 240/120V
$3,100.000
30 kVA Three Phase Transformer 480V to 240/120V. 30 kVA; three phase; 480 V delta. Contact Bluegrass Shipping Containers for availability and delivery details.
Description
Find the 30 kVA Three Phase Transformer 480V to 240/120V in the Bluegrass Shipping Containers accessories & parts range. Review the model details below to compare size, construction and equipment compatibility before choosing your configuration.
Specifications and equipment
- Rating: 30 kVA
- Phase: three phase
- Primary: 480 V delta
- Secondary: 240 V delta with 120 V lighting tap
- Type: ventilated dry type
- Winding material: aluminium
- Insulation class: 220°C
- Temperature rise: 150°C
- Frequency: 60 Hz
- Enclosure: NEMA 1 (indoor); weather shield WS58 available for outdoor use
- Mounting: surface
- Frame size: FR912B / FR940
- Reverse feed: capable
- Reference: Eaton V48M22T3016
- 240 Delta With a Lighting Tap
- NEMA 1 Means Indoors
Ask about this product
Contact Bluegrass Shipping Containers with product reference BGC-PROPANE-835 and your delivery ZIP code to confirm availability, included equipment and delivery arrangements.
